Rl-2 Load Haul Dump Machine With Detuz Engine 4000kg Underground Mining Scoop
Description
The trusted workhorse of miners and tunneling professionals, the RL-2 Load-Haul-Dump Machine is ideal for small to medium scale rock excavation operations. The RL-2 maintains the simple yet very robust design tenets of what a mining equipment should be - it has a
small footprint and turning radius suitable for small envelope sizes, high proven reliability,and straight-forward mechanical components that are easy to maintain.
Main Components
Manufacturer DEUTZ
Model BF4M1013EC
Type Water cooled diesel engine
Rated power 115KW/2300rpm
- Hydraulic torque converter
Manufacturer DANA
Model C272
Type Single stage two components with hydraulic pump drive
Manufacturer DANA
Model R32000
Type Power shift
Manufacturer Meitong, Xuzhou
Type Rigid planetary transmission bridge with NO-SPIN anti-skid differential
Include Service brake, Parking brake
Design SAHR brake for service brake and parking brake, the SAHR brakes on axle will act as both service and park brake
Include Working system, Steering system, Braking system, Filling system
Design The main components are imported from abroad
Technical Datas
1. Dimension
Rated capacity 4,000kg
Length 7300±100mm
Width 1840±50mm
Height 1960±50mm
Standard bucket 2 m³
Max. Lifting height 4070±100 mm
Max. Unloading height 1880mm
Min. Unloading distance ≥740 mm
Unloading angel 40°
Wheelbase 2540±15mm
Min. Ground clearance ≥250mm
Departure angle 15°
Rear axle swing angle ±6°~±8°
2. Weight 12900kg
Heavy duty weight ≤16900kg
3.Speed 1st gear 3.8±0.5 km/h
2nd gear 7.8±0.5 km/h
3rd gear 17.5±1.0 km/h
Gradeability ≥12°(Heavy loaded)
Maximum traction ≥110KN
Maximum scooping force(SAE) ≥90KN
4.Hydraulic system
Working system rated pressure: 14MPa
Steering system rated pressure: 14MPa
Brake system rated pressure: 12.5MPa
Hydraulic hoses JIC37
5.Tank
Fuel tank 100L
Hydraulic oil tank 120L
6. Electric system
Working voltage 24V
7. Driver’s cab
Horizontal
8. Steering
Central articulated hydraulic power steering, controller by Joystick
Steering angle ±42°
Min. Turning radius Inner ≤ 4255mm
Outer ≤ 6500mm
Our comapny
KSQ Technologies (Beijing) Co. Ltd. is a diversified enterprise based in Beijing, China, offering a portfolio of products that help contribute to a better bottom line and increase workplace safety for the construction and mining industries.
KSQ Technologies (Beijing) Co. Ltd. has significant experience and know-how in the supply of materials, components, finished goods, specially designed/engineered equipment, and services from China. The company caters to medium to large scale clients who are doing projects and capital expansion, as well as to firms who require support with consumable products, maintenance, and repair operations. Our operations are based on the unique expertise of our people and knowledge with customer processes.
Our portfolio includes:
Consumables used in the mining and construction industries
Equipment used in the mining and construction industries
Spare parts used for the equipment we sell for the mining and construction industries
Green technologies, such as products that reduce electric consumption or use alternate sources of energy (solar, wind, etc.)
